Louisville Custom Iron Gates Company offers gate installation services in the Louisville area. We can design a gate to your liking or install a gate you've already purchased. We handle everything from setting posts to hanging and adjusting the gate. Our crews will check the opening and site conditions before choosing the post setting, hardware, and final adjustments the gate needs.
Your project won’t be complete until the gate system works for you. The finished gate will move freely and work well with the latch without having to be forced into place. For all automatic installations, we will make sure the operator, power supply, and safety equipment work.
Get a Free Quote on Gate Installation
What Gate Installation Actually Involves
Gate installation is mostly groundwork. The gate itself gets hung in an afternoon; what determines whether it still closes properly in five years is what happens before that, in the survey, the post setting and the hardware adjustment. A gate is a heavy object cantilevered off a single vertical support, and almost every long-term fault traces back to that support rather than to the gate.
The sequence is the same regardless of what kind of gate is going in: survey and measure, confirm the configuration, set or assess the posts, hang the leaf, fit and adjust the hardware, then test. Automation, if any, goes on after the gate is proven to move freely by hand.
Installation is quoted after a site visit, not from a photograph. We measure the opening between finished post faces, shoot the ground profile through the travel of the gate and check what is underground before giving you a figure.
- Footings 36–42" deep, below the frost line
- 4"×4" and 6"×6" posts at 3/16" wall
- Gates we build and gates supplied by others
The Site Survey: What Gets Measured and Why
The first visit is measurement and constraints. Opening width between the finished faces of the posts or piers, not between the fence line. Height available, and what the gate has to line up with on either side. Ground profile through the full travel of the gate, because a level-looking drive often falls an inch or two across a ten-foot opening and that inch decides the ground clearance.
Then the things that are easy to miss: where the utilities run, because posts mean digging; which way water moves across the opening; what is overhead; how the ground is made up, since a post going into fill behaves very differently from one going into undisturbed clay. Where an opening sits next to a wall, a hedge or a parked vehicle, the real obstruction gets noted rather than the one on the plan.
That survey is what settles the configuration. A gate that will not clear the ground, or that fouls a wall at seventy degrees, is a design problem rather than an installation problem, and it is far cheaper to find on the first visit than on the day the gate arrives.
Posts, Footings and Why Depth Matters
The hinge post carries the entire weight of the gate as a lever. That load is trying to rotate the post out of the ground, which is why a hinge post needs a deeper and wider footing than the latch post on the other side, even though they look identical above ground.
Footing depth is set by three things: the weight and length of the leaf, the post size, and the soil. It also has to get below the local frost line, because water in the soil around a shallow footing expands as it freezes and lifts the post a fraction each winter. A gate that has drifted out of alignment over several years, with no single event to blame, has usually been moved by frost.
Concrete needs to cure before the gate goes on. On most residential jobs that means the posts are set on one visit and the gate is hung on another, normally a few days later. Hanging a heavy leaf on green concrete is the quickest way to pull a post out of plumb, and it is not worth saving the trip.
Where posts already exist, whether they are masonry piers, timber, or steel set by a previous installer, they get assessed before anything is hung on them. Plumb, movement at the base, corrosion at ground level and the depth they appear to be set to all matter. A sound existing pier saves real money; one that is already leaning will simply carry the new gate downhill with it.
Hanging the Gate and Setting the Hardware
The leaf is hung, levelled and shimmed to the hinge line, and the gap at the latch side is set. That gap is deliberately consistent top to bottom, because a tapering gap is the first visible sign that something is not square, and it is much easier to correct on installation day than later.
Hardware then gets adjusted rather than just fitted. Hinge tension, latch engagement, stop position and, where fitted, the closing speed of a self-closing hinge or closer are all set against the gate's actual weight. A latch that engages when the gate is pushed firmly but not when it swings shut on its own has not been adjusted, and on a pool or street-facing gate that difference matters.
Stops are fitted so the leaf cannot swing past its hinge line in wind. This is a small detail that prevents a large repair, since a gate blown back on itself will bend the hinge plate or crack the weld behind it.
What Gets Checked Before We Leave
The gate is cycled repeatedly through its full travel by hand, watching for any point where it binds, drags or changes effort. It should feel the same at ten degrees and at ninety.
Clearance is checked at the point where the ground is highest, not where it is convenient. Latch engagement is tested from a closing swing rather than a push. Where the gate meets a fence or wall, the gaps get checked against anything that could trap a hand or let a small dog through.
If an operator is being fitted, that happens only once the gate moves freely without it. Automation applied to a gate that already drags will mask the problem for a while and then break something, which is why the mechanical side is signed off first. Details of that side of the work are on our automatic gate installation page.
What Affects the Timeline
For a gate we are building, the long pole is fabrication and finishing rather than installation. Once the design is signed off, the gate has to be cut, welded, fitted up, blasted, primed and coated, and coating in particular is weather and schedule dependent.
On site, the variables are whether new posts are needed, whether anything has to be dug through, and whether power or control wiring is being run at the same time. A gate going onto existing sound posts with no automation is usually a single visit. New posts add a curing gap. Trenching for power adds whatever the ground and the route demand.
We will give you a date rather than a range once the design is fixed, and tell you plainly if weather is likely to move it.
Preparing Your Property Before Installation Day
There is not much to do, but a few things help. Clear vehicles and anything stored within about ten feet of the opening on both sides. If there is a hedge or planting right at the post positions, cutting it back beforehand saves us doing it less carefully.
If you know where private utilities run, irrigation lines, low-voltage lighting cable, a dog fence loop, a septic run, tell us before we dig. Public utilities get located as a matter of course, but private lines installed by a previous owner are invisible to that process and are the ones most often cut.
Where the work involves an existing gate coming out, it is worth deciding in advance whether you want it taken away or left on site. Old ironwork is sometimes worth keeping for a pattern, and it is easier to set aside than to retrieve.
Gate Installation Across Greater Louisville
We install gates across Louisville Metro, from the narrow lots of Clifton and the Highlands to estate drives in Anchorage and Pewee Valley. Footing depth, not postcode, is what changes between them.
Gate Installation FAQs
How long does gate installation take on site?
Most single residential gates are hung in a day once the posts have cured. Where new posts are being set, the concrete normally needs to cure before the gate is hung, so the work is usually split across two visits.
Will you install a gate I bought elsewhere?
Often yes. We will want the gate's weight, dimensions and hinge requirements first, because a gate sold as a standard panel does not always suit the opening or the posts it is going onto.
How deep do gate posts need to be set?
Depth depends on gate weight, post size and soil, and the footing needs to reach below the local frost line. A hinge post carrying a heavy leaf needs a deeper and wider footing than a latch post.
Do I need a permit to install a gate in Louisville?
It depends on the jurisdiction, the location of the gate and whether it forms part of a pool barrier or sits near a public right of way. Requirements should be confirmed for the specific address before installation.
Can a gate be installed if the posts are already in place?
Yes, provided the existing posts are plumb, sound and set deep enough for the gate's weight. Those get checked first, because hanging a new gate on a post that is already moving simply transfers the problem.
What is covered once the gate is installed?
Workmanship on posts, footings and hanging is covered, and any operator fitted carries its manufacturer's warranty. We put the specifics in writing with the quote rather than leaving it vague.
How far out do your installers travel?
Across Jefferson County and into Oldham County, including Crestwood and Pewee Valley. If you are on the edge of that, call and we will tell you straight away rather than sending someone to look.
